Pitch 0.75inch/19.05mm

Thickness:8.2mm

Color: White, Blue, Brown

Standard Width: Multiple of 76.2mm

Optional Width: Added by 19.05,19.05…mm based on 228.6mm

Belt Load: PP=11800N/M; POM=20700N/M

Thickness:8.2mm         Open rate:36.9%

Color: White, Blue, Brown

Standard Width: Multiple of 76.2mm

Optional Width: Added by 19.05,19.05…mm based on 228.6mm

Belt Load: PP=11800N/M; POM=20700N/M

Thickness:8.2mm         Open rate:6.2%

Color: White, Blue, Brown

Standard Width: Multiple of 76.2mm

Optional Width: Added by 19.05,19.05…mm based on 228.6mm

Belt Load: PP=11800N/M; POM=20700N/M

Baffle Standard Height: 10,25,50mm. Can be cut as required.

Side guard standard Height: 50mm. Edge distance: Multiple of 19.05mm

9T   Round hole: Φ25mm, Keynote:4x8mm

13T  Round hole: Φ25mm, Keynote:4x8mm

17T  Round hole: Φ25mm, Keynote:4x8mm

24T  Round hole: Φ25,30,40 mm, Keynote:4x8mm     Square hole:40x40
